#include <cooperative_groups.h>
#include <cuda/barrier>

__global__ void stencil_kernel(const float *left, const float *center, const float *right)
{
    auto block = cooperative_groups::this_thread_block();
    auto thread = cooperative_groups::this_thread();
    using barrier_t = cuda::barrier<cuda::thread_scope_block>;
    __shared__ barrier_t barrier;
    __shared__ float buffer[8 + 32 + 8];

    // 初始化同步对象。
    if (block.thread_rank() == 0) {
        init(&barrier, block.size());
    }
    __syncthreads();

    // 版本 1：在各个线程中发起复制。
    if (tid < 8) {
        cuda::memcpy_async(buffer + tid, left + tid, cuda::aligned_size_t<4>(sizeof(float)), barrier); // 左光晕
        // 或 cuda::memcpy_async(thread, buffer + tid, left + tid, cuda::aligned_size_t<4>(sizeof(float)), barrier);
    } else if (tid >= 32 - 8) {
        cuda::memcpy_async(buffer + tid + 16, right + tid, cuda::aligned_size_t<4>(sizeof(float)), barrier); // 右光晕
        // 或 cuda::memcpy_async(thread, buffer + tid + 16, right + tid, cuda::aligned_size_t<4>(sizeof(float)), barrier);
    }
    if (tid < 32) {
        cuda::memcpy_async(buffer + 40, right + tid, cuda::aligned_size_t<4>(sizeof(float)), barrier); // 中心
        // 或 cuda::memcpy_async(thread, buffer + 40, right + tid, cuda::aligned_size_t<4>(sizeof(float)), barrier);
    }

    // 版本 2：在所有线程间协作发起复制。
    cuda::memcpy_async(block, buffer, left, cuda::aligned_size_t<4>(8 * sizeof(float)), barrier); // 左光晕
    cuda::memcpy_async(block, buffer + 8, center, cuda::aligned_size_t<4>(32 * sizeof(float)), barrier); // 中心
    cuda::memcpy_async(block, buffer + 40, right, cuda::aligned_size_t<4>(8 * sizeof(float)), barrier); // 右光晕

    // 等待所有复制完成。
    barrier.arrive_and_wait();
    __syncthreads();

    // 计算模板
}

#include <cooperative_groups.h>
#include <cooperative_groups/memcpy_async.h>

namespace cg = cooperative_groups;

__global__ void stencil_kernel(const float *left, const float *center, const float *right)
{
    cg::thread_block block = cg::this_thread_block();
    // 左侧光晕（8个元素）- 中心（32个元素）- 右侧光晕（8个元素）。
    __shared__ float buffer[8 + 32 + 8];

    // 在所有线程间协作发起复制操作。
    cg::memcpy_async(block, buffer, left, 8 * sizeof(float)); // 左侧光晕
    cg::memcpy_async(block, buffer + 8, center, 32 * sizeof(float)); // 中心
    cg::memcpy_async(block, buffer + 40, right, 8 * sizeof(float)); // 右侧光晕
    cg::wait(block); // 等待所有复制操作完成。
    __syncthreads();

    // 计算模板。
}

#include <cuda_pipeline.h>

__global__ void stencil_kernel(const float *left, const float *center, const float *right)
{
    // 左侧光晕（8个元素）- 中心（32个元素）- 右侧光晕（8个元素）。
    __shared__ float buffer[8 + 32 + 8];
    const int tid = threadIdx.x;

    if (tid < 8) {
        __pipeline_memcpy_async(buffer + tid, left + tid, sizeof(float)); // 左侧光晕
    } else if (tid >= 32 - 8) {
        __pipeline_memcpy_async(buffer + tid + 16, right + tid, sizeof(float)); // 右侧光晕
    }
    if (tid < 32) {
        __pipeline_memcpy_async(buffer + tid + 8, center + tid, sizeof(float)); // 中心
    }
    __pipeline_commit();
    __pipeline_wait_prior(0);
    __syncthreads();

    // 计算模板。
}

#include <cooperative_groups.h>
#include <cuda/pipeline>

template <size_t num_stages = 2 /* Pipeline with num_stages stages */>
__global__ void prefetch_kernel(int* global_out, int const* global_in, size_t size, size_t batch_size) {
    auto grid = cooperative_groups::this_grid();
    auto block = cooperative_groups::this_thread_block();
    auto thread = cooperative_groups::this_thread();
    assert(size == batch_size * grid.size()); // Assume input size fits batch_size * grid_size

    extern __shared__ int shared[]; // num_stages * block.size() * sizeof(int) bytes
    size_t shared_offset[num_stages];
    for (int s = 0; s < num_stages; ++s) shared_offset[s] = s * block.size();

    cuda::pipeline<cuda::thread_scope_thread> pipeline = cuda::make_pipeline();

    auto block_batch = [&](size_t batch) -> int {
        return block.group_index().x * block.size() + grid.size() * batch;
    };

    // Fill the pipeline with the first ``num_stages`` batches.
    for (int s = 0; s < num_stages; ++s) {
        pipeline.producer_acquire();
        cuda::memcpy_async(shared + shared_offset[s] + tid, global_in + block_batch(s) + tid, cuda::aligned_size_t<4>(sizeof(int)), pipeline);
        pipeline.producer_commit();
    }

    int stage = 0;

    // compute_batch: next batch to process
    // fetch_batch:   next batch to fetch from global memory
    for (size_t compute_batch = 0, fetch_batch = num_stages; compute_batch < batch_size; ++compute_batch, ++fetch_batch) {
        // Wait for the first requested stage to complete.
        constexpr size_t pending_batches = num_stages - 1;
        cuda::pipeline_consumer_wait_prior<pending_batches>(pipeline);
        __syncthreads(); // Not required if each thread works on the data it copied.

        // Compute on the current batch
        compute(global_out + block_batch(compute_batch) + tid, shared + shared_offset[stage] + tid);

        // Release the current stage.
        pipeline.consumer_release();
        __syncthreads(); // Not required if each thread works on the data it copied.

        // Load future stage ``num_stages`` ahead of current compute batch.
        pipeline.producer_acquire();
        if (fetch_batch < batch_size) {
            cuda::memcpy_async(shared + shared_offset[stage] + tid, global_in + block_batch(fetch_batch) + tid, cuda::aligned_size_t<4>(sizeof(int)), pipeline);
        }
        pipeline.producer_commit();
        stage = (stage + 1) % num_stages;
    }
}

#include <cooperative_groups.h>
#include <cooperative_groups/memcpy_async.h>

namespace cg = cooperative_groups;

template <size_t num_stages = 2 /* 包含 num_stages 个阶段的流水线 */>
__global__ void prefetch_kernel(int* global_out, int const* global_in, size_t size, size_t batch_size) {
    auto grid = cooperative_groups::this_grid();
    auto block = cooperative_groups::this_thread_block();
    assert(size == batch_size * grid.size()); // 假设输入大小符合 batch_size * grid_size

    extern __shared__ int shared[]; // num_stages * block.size() * sizeof(int) 字节
    size_t shared_offset[num_stages];
    for (int s = 0; s < num_stages; ++s) shared_offset[s] = s * block.size();

    cuda::pipeline<cuda::thread_scope_thread> pipeline = cuda::make_pipeline();

    auto block_batch = [&](size_t batch) -> int {
        return block.group_index().x * block.size() + grid.size() * batch;
    };

    // 用前 ``num_stages`` 个批次填充流水线。
    for (int s = 0; s < num_stages; ++s) {
        size_t block_batch_idx = block_batch(s);
        cg::memcpy_async(block, shared + shared_offset[s], global_in + block_batch_idx, cuda::aligned_size_t<4>(sizeof(int));
    }

    int stage = 0;

    // compute_batch: 下一个要处理的批次
    // fetch_batch:   下一个要从全局内存获取的批次
    for (size_t compute_batch = 0, fetch_batch = num_stages; compute_batch < batch_size; ++compute_batch, ++fetch_batch) {
        // 等待第一个请求的阶段完成。
        size_t pending_batches = (fetch_batch < batch_size - num_stages) ? num_stages - 1 : batch_size - fetch_batch - 1;
        cg::wait_prior(pending_batches);
        __syncthreads(); // 如果每个线程处理自己复制的数据，则不需要。

        // 在当前批次上进行计算。
        compute(global_out + block_batch(compute_batch) + tid, shared + shared_offset[stage] + tid);

        __syncthreads(); // 如果每个线程处理自己复制的数据，则不需要。

        // 加载当前计算批次之前 ``num_stages`` 个阶段的未来数据。
        size_t fetch_batch_idx = block_batch(fetch_batch);
        if (fetch_batch < batch_size) {
            cg::memcpy_async(block, shared + shared_offset[stage], global_in + block_batch(fetch_batch), cuda::aligned_size_t<4>(sizeof(int)) * block.size());
        }
        stage = (stage + 1) % num_stages;
    }
}

#include <cooperative_groups.h>
#include <cuda_awbarrier_primitives.h>

template <size_t num_stages = 2 /* 包含 num_stages 个阶段的流水线 */>
__global__ void prefetch_kernel(int* global_out, int const* global_in, size_t size, size_t batch_size) {
    auto grid = cooperative_groups::this_grid();
    auto block = cooperative_groups::this_thread_block();
    assert(size == batch_size * grid.size()); // 假设输入大小符合 batch_size * grid_size

    extern __shared__ int shared[]; // num_stages * block.size() * sizeof(int) 字节
    size_t shared_offset[num_stages];
    for (int s = 0; s < num_stages; ++s) shared_offset[s] = s * block.size();

    auto block_batch = [&](size_t batch) -> int {
        return block.group_index().x * block.size() + grid.size() * batch;
    };

    // 用前 ``num_stages`` 个批次填充流水线。
    for (int s = 0; s < num_stages; ++s) {
        __pipeline_memcpy_async(shared + shared_offset[s] + tid, global_in + block_batch(s)+ tid, cuda::aligned_size_t<4>(sizeof(int)));
        __pipeline_commit();
    }

    // compute_batch: 下一个要处理的批次
    // fetch_batch:   下一个要从全局内存获取的批次
    for (size_t compute_batch = 0, fetch_batch = num_stages; compute_batch < batch_size; ++compute_batch, ++fetch_batch) {
        // 等待第一个请求的阶段完成。
        constexpr size_t pending_batches = num_stages - 1;
        __pipeline_wait_prior<pending_batches>();
        __syncthreads(); // 如果每个线程处理自己复制的数据，则不需要。

        // 在当前批次上进行计算。
        compute(global_out + block_batch(compute_batch) + tid, shared + shared_offset[stage] + tid);

        __syncthreads(); // 如果每个线程处理自己复制的数据，则不需要。

        // 加载当前计算批次之前 ``num_stages`` 个阶段的未来数据。
        if (fetch_batch < batch_size) {
            __pipeline_memcpy_async(shared + shared_offset[stage] + tid, global_in + block_batch(fetch_batch) + tid, cuda::aligned_size_t<4>(sizeof(int)));
        }
        __pipeline_commit();
        stage = (stage + 1) % num_stages;
    }
}

#include <cooperative_groups.h>
#include <cuda/pipeline>

#pragma nv_diag_suppress static_var_with_dynamic_init

using pipeline = cuda::pipeline<cuda::thread_scope_block>;

__device__ void produce(pipeline &pipe, int num_stages, int stage, int num_batches, int batch, float *buffer, int buffer_len, float *in, int N)
{
  if (batch < num_batches)
  {
    pipe.producer_acquire();
    /* copy data from in(batch) to buffer(stage) using asynchronous memory copies */
    cuda::memcpy_async(buffer + stage * buffer_len + threadIdx.x, in + batch * buffer_len + threadIdx.x, cuda::aligned_size_t<4>(sizeof(float)), pipe);
    pipe.producer_commit();
  }
}

__device__ void consume(pipeline &pipe, int num_stages, int stage, int num_batches, int batch, float *buffer, int buffer_len, float *out, int N)
{
  pipe.consumer_wait();
  /* consume buffer(stage) and update out(batch) */
  pipe.consumer_release();
}

__global__ void producer_consumer_pattern(float *in, float *out, int N, int buffer_len)
{
  auto block = cooperative_groups::this_thread_block();
  constexpr int warpSize = 32;

  /* Shared memory buffer declared below is of size 2 * buffer_len
     so that we can alternatively work between two buffers.
     buffer_0 = buffer and buffer_1 = buffer + buffer_len */
  __shared__ extern float buffer[];

  const int num_batches = N / buffer_len;

  // Create a partitioned pipeline with 2 stages where the first warp is the producer and the other warps are consumers.
  constexpr auto scope = cuda::thread_scope_block;
  constexpr int num_stages = 2;
  cuda::std::size_t producer_count = warpSize;
  __shared__ cuda::pipeline_shared_state<scope, num_stages> shared_state;
  pipeline pipe = cuda::make_pipeline(block, &shared_state, producer_count);

  // Producer fills the pipeline
  if (block.thread_rank() < producer_count)
    for (int s = 0; s < num_stages; ++s)
      produce(pipe, num_stages, s, num_batches, s, buffer, buffer_len, in, N);

  // Process the batches
  int stage = 0;
  for (size_t b = 0; b < num_batches; ++b)
  {
    if (block.thread_rank() < producer_count)
    {
      // Producers prefetch the next batch
      produce(pipe, num_stages, stage, num_batches, b + num_stages, buffer, buffer_len, in, N);
    }
    else
    {
      // Consumers consume the oldest batch
      consume(pipe, num_stages, stage, num_batches, b, buffer, buffer_len, out, N);
    }
    stage = (stage + 1) % num_stages;
  }
}

#include <cooperative_groups.h>
#include <cuda_awbarrier_primitives.h>

__device__ void produce(__mbarrier_t ready[], __mbarrier_t filled[], float *buffer, int buffer_len, float *in, int N)
{
  for (int i = 0; i < N / buffer_len; ++i)
  {
    __mbarrier_token_t token = __mbarrier_arrive(&ready[i % 2]); /* 等待 buffer_(i%2) 准备好被填充 */
    while(!__mbarrier_try_wait(&ready[i % 2], token, 1000)) {}
    /* 生产，即填充 buffer_(i%2) */
    __pipeline_memcpy_async(buffer + i * buffer_len + threadIdx.x, in + i * buffer_len + threadIdx.x, cuda::aligned_size_t<4>(sizeof(float)));
    __pipeline_arrive_on(filled[i % 2]);
    __mbarrier_arrive(filled[i % 2]);  /* buffer_(i%2) 已填充 */
  }
}

__device__ void consume(__mbarrier_t ready[], __mbarrier_t filled[], float *buffer, int buffer_len, float *out, int N)
{
  __mbarrier_arrive(&ready[0]); /* buffer_0 准备好进行初始填充 */
  __mbarrier_arrive(&ready[1]); /* buffer_1 准备好进行初始填充 */
  for (int i = 0; i < N / buffer_len; ++i)
  {
    __mbarrier_token_t token = __mbarrier_arrive(&filled[i % 2]);
    while(!__mbarrier_try_wait(&filled[i % 2], token, 1000)) {}
    /* 消费 buffer_(i%2) */
    __mbarrier_arrive(&ready[i % 2]); /* buffer_(i%2) 准备好被重新填充 */
  }
}

__global__ void producer_consumer_pattern(int N, float *in, float *out, int buffer_len)
{

  /* 下面声明的共享内存缓冲区大小为 2 * buffer_len，
     以便我们可以在两个缓冲区之间交替工作。
     buffer_0 = buffer 且 buffer_1 = buffer + buffer_len */
  __shared__ extern float buffer[];

  /* bar[0] 和 bar[1] 跟踪缓冲区 buffer_0 和 buffer_1 是否准备好被填充，
     而 bar[2] 和 bar[3] 分别跟踪缓冲区 buffer_0 和 buffer_1 是否已被填充 */
  __shared__ __mbarrier_t bar[4];

  // 初始化屏障
  auto block = cooperative_groups::this_thread_block();
  if (block.thread_rank() < 4)
    __mbarrier_init(bar + block.thread_rank(), block.size());
  __syncthreads();

  if (block.thread_rank() < warpSize)
    produce(bar, bar + 2, buffer, buffer_len, in, N);
  else
    consume(bar, bar + 2, buffer, buffer_len, out, N);
}

#include <cuda/barrier>
#include <cuda/ptx>

using barrier = cuda::barrier<cuda::thread_scope_block>;
namespace ptx = cuda::ptx;

static constexpr size_t buf_len = 1024;

__device__ inline bool is_elected()
{
    unsigned int tid = threadIdx.x;
    unsigned int warp_id = tid / 32;
    unsigned int uniform_warp_id = __shfl_sync(0xFFFFFFFF, warp_id, 0); // Broadcast from lane 0.
    return (uniform_warp_id == 0 && ptx::elect_sync(0xFFFFFFFF)); // Elect a leader thread among warp 0.
}

__global__ void add_one_kernel(int* data, size_t offset)
{
  // Shared memory buffer. The destination shared memory buffer of
  // a bulk operation should be 16 byte aligned.
  __shared__ alignas(16) int smem_data[buf_len];

  // 1. Initialize shared memory barrier with the number of threads participating in the barrier.
  #pragma nv_diag_suppress static_var_with_dynamic_init
  __shared__ barrier bar;
  if (threadIdx.x == 0) {
    init(&bar, blockDim.x);
  }
  __syncthreads();

  // 2. Initiate TMA transfer to copy global to shared memory from a single thread.
  if (is_elected()) {
    // Launch the async copy and communicate how many bytes are expected to come in (the transaction count).

    // Version 1: cuda::memcpy_async
    cuda::memcpy_async(
        smem_data, data + offset,
        cuda::aligned_size_t<16>(sizeof(smem_data)),
        bar);

    // Version 2: cuda::device::memcpy_async_tx
    // cuda::device::memcpy_async_tx(
    //   smem_data, data + offset,
    //   cuda::aligned_size_t<16>(sizeof(smem_data)),
    //   bar);
    // cuda::device::barrier_expect_tx(
    //     cuda::device::barrier_native_handle(bar),
    //     sizeof(smem_data));

    // Version 3: cuda::ptx::cp_async_bulk
    // ptx::cp_async_bulk(
    //     ptx::space_shared, ptx::space_global,
    //     smem_data, data + offset,
    //     sizeof(smem_data),
    //     cuda::device::barrier_native_handle(bar));
    // cuda::device::barrier_expect_tx(
    //     cuda::device::barrier_native_handle(bar),
    //     sizeof(smem_data));
  }

  // 3a. All threads arrive on the barrier.
  barrier::arrival_token token = bar.arrive();

  // 3b. Wait for the data to have arrived.
  bar.wait(std::move(token));

  // 4. Compute saxpy and write back to shared memory.
  for (int i = threadIdx.x; i < buf_len; i += blockDim.x) {
    smem_data[i] += 1;
  }

  // 5. Wait for shared memory writes to be visible to TMA engine.
  ptx::fence_proxy_async(ptx::space_shared);
  __syncthreads();
  // After syncthreads, writes by all threads are visible to TMA engine.

  // 6. Initiate TMA transfer to copy shared memory to global memory.
  if (is_elected()) {
    ptx::cp_async_bulk(
        ptx::space_global, ptx::space_shared,
        data + offset, smem_data, sizeof(smem_data));
    // 7. Wait for TMA transfer to have finished reading shared memory.
    // Create a "bulk async-group" out of the previous bulk copy operation.
    ptx::cp_async_bulk_commit_group();
    // Wait for the group to have completed reading from shared memory.
    ptx::cp_async_bulk_wait_group_read(ptx::n32_t<0>());
  }
}

#include <cooperative_groups.h>
#include <cuda/barrier>
#include <cuda/ptx>

namespace ptx = cuda::ptx;
namespace cg = cooperative_groups;

__device__ inline bool is_elected()
{
    unsigned int tid = threadIdx.x;
    unsigned int warp_id = tid / 32;
    unsigned int uniform_warp_id = __shfl_sync(0xFFFFFFFF, warp_id, 0); // 从通道 0 广播。
    return (uniform_warp_id == 0 && ptx::elect_sync(0xFFFFFFFF)); // 在线程束 0 中选出一个领导线程。
}

template <int block_size, int num_stages>
__global__ void prefetch_kernel(int* global_out, int const* global_in, size_t size, size_t batch_size) {
    auto grid = cg::this_grid();
    auto block = cg::this_thread_block();
    const int tid = threadIdx.x;
    assert(size == batch_size * grid.size()); // 假设输入大小符合 batch_size * grid_size

    // 1. 初始化阶段
    __shared__ int shared[num_stages * block_size];
    size_t shared_offset[num_stages];
    for (int s = 0; s < num_stages; ++s) shared_offset[s] = s * block.size();

    auto block_batch = [&](size_t batch) -> int {
        return block.group_index().x * block.size() + grid.size() * batch;
    };

    // 使用参与屏障的线程数初始化共享内存屏障。
    // 我们将为屏障使用显式的阶段跟踪，这允许我们只让一个线程到达屏障来设置事务计数，
    // 而其他线程等待基于奇偶性的阶段翻转。
    #pragma nv_diag_suppress static_var_with_dynamic_init
    __shared__ cuda::barrier<cuda::thread_scope_block> bar[num_stages];
    if (tid == 0) {
        #pragma unroll num_stages
        for (int i = 0; i < num_stages; i++) {
            init(&bar[i], 1);
        }
    }
    __syncthreads();

    // 用前 ``num_stages`` 个批次填充流水线。
    if (is_elected()) {
        size_t num_bytes = block_size * sizeof(int);

        #pragma unroll num_stages
        for (int s = 0; s < num_stages; ++s) {
            cuda::device::memcpy_async_tx(&shared[shared_offset[s]], &global_in[block_batch(s)], cuda::aligned_size_t<16>(num_bytes), bar[s]);
            (void)cuda::device::barrier_arrive_tx(bar[s], 1, num_bytes);
        }
    }

    // 2. 主处理循环。
    // compute_batch: 下一个要处理的批次。
    // fetch_batch:   下一个要从全局内存获取的批次。
    int stage = 0;       // 共享内存缓冲区中的当前阶段。
    uint32_t parity = 0; // 屏障奇偶性。
    for (size_t compute_batch = 0, fetch_batch = num_stages; compute_batch < batch_size; ++compute_batch, ++fetch_batch) {
        // (a) 等待当前批次。
        while (!ptx::mbarrier_try_wait_parity(ptx::sem_acquire, ptx::scope_cta, cuda::device::barrier_native_handle(bar[stage]), parity)) {}

        // (b) 在当前批次上进行计算。
        compute(global_out + block_batch(compute_batch) + tid, shared + shared_offset[stage] + tid);
        __syncthreads();

        // (c) 加载当前计算批次前方 ``num_stages`` 个阶段的下一个阶段。
        if (is_elected() && fetch_batch < batch_size) {
            size_t num_bytes = block_size * sizeof(int);
            cuda::device::memcpy_async_tx(&shared[shared_offset[stage]], &global_in[block_batch(fetch_batch)], cuda::aligned_size_t<16>(num_bytes), bar[stage]);
            (void)cuda::device::barrier_arrive_tx(bar[stage], 1, num_bytes);
        }

        // (d) 阶段管理。
        stage++;
        if (stage == num_stages) {
            stage = 0;
            parity ^= 1;
        }
    }
}

#include <cuda.h>

__global__ void kernel(const __grid_constant__ CUtensorMap tensor_map)
{
   // Use tensor_map here.
}
int main() {
  CUtensorMap map;
  // [ ..Initialize map.. ]
  kernel<<<1, 1>>>(map);
}

#include <cuda.h>

__constant__ CUtensorMap global_tensor_map;
__global__ void kernel()
{
  // Use global_tensor_map here.
}
int main() {
  CUtensorMap local_tensor_map;
  // [ ..Initialize map.. ]
  cudaMemcpyToSymbol(global_tensor_map, &local_tensor_map, sizeof(CUtensorMap));
  kernel<<<1, 1>>>();
}

#include <cuda.h>
#include <cuda/ptx>
namespace ptx = cuda::ptx;

__device__ CUtensorMap global_tensor_map;
__global__ void kernel(CUtensorMap *tensor_map)
{
  // Fence acquire tensor map:
  ptx::n32_t<128> size_bytes;
  // Since the tensor map was modified from the host using cudaMemcpy,
  // the scope should be .sys.
  ptx::fence_proxy_tensormap_generic(
     ptx::sem_acquire, ptx::scope_sys, tensor_map, size_bytes
 );
 // Safe to use tensor_map after fence inside this thread.
}
int main() {
  CUtensorMap local_tensor_map;
  // [ ..Initialize map.. ]
  cudaMemcpy(&global_tensor_map, &local_tensor_map, sizeof(CUtensorMap), cudaMemcpyHostToDevice);
  kernel<<<1, 1>>>(global_tensor_map);
}

#include <cuda.h>         // CUtensormap
#include <cuda/barrier>

using barrier = cuda::barrier<cuda::thread_scope_block>;
namespace ptx = cuda::ptx;

__device__ inline bool is_elected()
{
    unsigned int tid = threadIdx.x;
    unsigned int warp_id = tid / 32;
    unsigned int uniform_warp_id = __shfl_sync(0xFFFFFFFF, warp_id, 0); // Broadcast from lane 0.
    return (uniform_warp_id == 0 && ptx::elect_sync(0xFFFFFFFF)); // Elect a leader thread among warp 0.
}

__global__ void kernel(const __grid_constant__ CUtensorMap tensor_map, int x, int y) {
  // The destination shared memory buffer of a bulk tensor operation should be
  // 128 byte aligned.
  __shared__ alignas(128) int smem_buffer[SMEM_HEIGHT][SMEM_WIDTH];

  // Initialize shared memory barrier with the number of threads participating in the barrier.
  #pragma nv_diag_suppress static_var_with_dynamic_init
  __shared__ barrier bar;

  if (threadIdx.x == 0) {
    // Initialize barrier. All `blockDim.x` threads in block participate.
    init(&bar, blockDim.x);
  }
  // Syncthreads so initialized barrier is visible to all threads.
  __syncthreads();

  barrier::arrival_token token;
  if (is_elected()) {
    // Initiate bulk tensor copy.
    int32_t tensor_coords[2] = { x, y };
    ptx::cp_async_bulk_tensor(
      ptx::space_shared, ptx::space_global,
      &smem_buffer, &tensor_map, tensor_coords,
      cuda::device::barrier_native_handle(bar));
    // Arrive on the barrier and tell how many bytes are expected to come in.
    token = cuda::device::barrier_arrive_tx(bar, 1, sizeof(smem_buffer));
  } else {
    // Other threads just arrive.
    token = bar.arrive();
  }
  // Wait for the data to have arrived.
  bar.wait(std::move(token));

  // Symbolically modify a value in shared memory.
  smem_buffer[0][threadIdx.x] += threadIdx.x;

  // Wait for shared memory writes to be visible to TMA engine.
  ptx::fence_proxy_async(ptx::space_shared);
  __syncthreads();
  // After syncthreads, writes by all threads are visible to TMA engine.

  // Initiate TMA transfer to copy shared memory to global memory
  if (is_elected()) {
    int32_t tensor_coords[2] = { x, y };
    ptx::cp_async_bulk_tensor(
      ptx::space_global, ptx::space_shared,
      &tensor_map, tensor_coords, &smem_buffer);
    // Wait for TMA transfer to have finished reading shared memory.
    // Create a "bulk async-group" out of the previous bulk copy operation.
    ptx::cp_async_bulk_commit_group();
    // Wait for the group to have completed reading from shared memory.
    ptx::cp_async_bulk_wait_group_read(ptx::n32_t<0>());
  }

  // Destroy barrier. This invalidates the memory region of the barrier. If
  // further computations were to take place in the kernel, this allows the
  // memory location of the shared memory barrier to be reused.
  if (threadIdx.x == 0) {
    (&bar)->~barrier();
  }
}

// 初始化设备上下文：
CUDA_CHECK(cudaDeviceSynchronize());

// 使用 cuTensorMapEncodeTiled 驱动函数创建张量映射模板
CUtensorMap template_tensor_map = make_tensormap_template();

// 在全局内存中分配张量映射和张量
CUtensorMap* global_tensor_map;
CUDA_CHECK(cudaMalloc(&global_tensor_map, sizeof(CUtensorMap)));
char* global_buf;
CUDA_CHECK(cudaMalloc(&global_buf, 8 * 256));

// 用数据填充全局缓冲区。
fill_global_buf<<<1, 1>>>(global_buf);

// 定义将在设备上创建的张量映射的参数。
tensormap_params p{};
p.global_address    = global_buf;
p.rank              = 2;
p.box_dim[0]        = 128; // 共享内存中的框宽度为完整缓冲区的一半
p.box_dim[1]        = 4;   // 共享内存中的框高度为完整缓冲区的一半
p.global_dim[0]     = 256; //
p.global_dim[1]     = 8;   //
p.global_stride[0]  = 256; //
p.element_stride[0] = 1;   //
p.element_stride[1] = 1;   //

// 在设备上编码 global_tensor_map：
encode_tensor_map<<<1, 32>>>(template_tensor_map, p, global_tensor_map);

// 在另一个内核中使用它：
consume_tensor_map<<<1, 1>>>(global_tensor_map);

// 检查错误：
CUDA_CHECK(cudaDeviceSynchronize());

struct tensormap_params {
  void* global_address;
  int rank;
  uint32_t box_dim[5];
  uint64_t global_dim[5];
  size_t global_stride[4];
  uint32_t element_stride[5];
};
